Reshaping your communication power.
Product Specs: Routers
| LOGiN/Cisco Router |
Based on CISCO3251MAR and 3201FESMIC.
Copper and fiber connections for WAN and LAN
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports
E0 router, WAN (MAR3251):
1 X Console port DB9
1 x RJ45
1 x SC fiber multimode 1300nm
E1 switch, LAN (FESMIC3201):
1 X RJ45
3 x SC fiber multimode 1300nm
1 X DC In 10-32 V
Copper and fiber connections for WAN and LAN
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -40 - +55 Celsius
Storage: -40 - +70 Celsius
Ports
E0 router, WAN (MAR3251):
1 X Console port DB9
1 x RJ45
1 x SC fiber multimode 1300nm
E1 switch, LAN (FESMIC3201):
1 X RJ45
3 x SC fiber multimode 1300nm
1 X DC In 10-32 V
VoIP Router
Analog VoIP Router with 2 telephone connections.
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -0 - +40 Celsius
Storage: -20 - +50 Celsius
Ports:
1 x Fiber SC Multimode (10/100 Mbps, 1300nm)
1 x RJ45, 100 Mbps
2 x Voice Port RJ11
1 X DSUB 9-p, Console
1 x DC in 10-32V, Mil connector
Designed to meet MIL-STD-810F & MIL-STD-461E
Temp ranges: Operating: -0 - +40 Celsius
Storage: -20 - +50 Celsius
Ports:
1 x Fiber SC Multimode (10/100 Mbps, 1300nm)
1 x RJ45, 100 Mbps
2 x Voice Port RJ11
1 X DSUB 9-p, Console
1 x DC in 10-32V, Mil connector
UIDM V2
19”/2 version of Innovative Concepts UIDM® V2 is a stand-alone tactical router designed
for ground and air systems with an Ethernet interface in a rugged format. When
connected to a radio, it sends interoperable digital data to a variety of military assets.
Designed to meet MIL-STD-810F & MIL-STD-461E
Connections:
2 x 38999
(for radios)
1 x HMC Fiber LAN 100Mbps
1 x DC in 10-32V
for ground and air systems with an Ethernet interface in a rugged format. When
connected to a radio, it sends interoperable digital data to a variety of military assets.
Designed to meet MIL-STD-810F & MIL-STD-461E
Connections:
2 x 38999
(for radios)
1 x HMC Fiber LAN 100Mbps
1 x DC in 10-32V
| For more specific information, or help specifying your system, click here. |
